GYS (A) 1020 Sheet Stacker is an accessory unit for the automatic cylinder screen printing machine. It is used to collect and pile paper which can improve your production efficiency.

• This unit consist of input-bracket mechanism, piling -board up-down mechanism and electric control system
• Input-bracket mechanism contains conveyor belts and blowing device. The conveyor belts are driven by a motor, which speed is adjusted by transducer. The blowing device is used to blow-up the paper to move a distance after the paper leave from the belt. The paper will continue by the airflow. When the blower is shut off, the paper drops down to the pile-board.
• The pushing mechanism is driven by pneumatic cylinder. The position of the cylinder is easily adjustable for different paper sizes.
• Note: the air compressor is not provided; the cylinder working air pressure is 0.4MPa
• Pile-board up-down mechanism is driven by four synchronous chains from an electromagnetic motor. The board can be stopped accurately to a certain level
• Electric control system is controlled by PLC. The system is convenient and safe
